Fire Rated 093V Expansion

Deep rigid “V” is joined at the bottom with a flexible connection allowing a full ⅜” in controlled movement. Pink coloring quickly indicates to inspectors that the product is fire rated. Listed under U300 and U400-Series Wall or Partition Design in the UL Fire Resistance Directory. UL Rated for 1 hour and 2 hour assembly, refer to UL Detail documentation for full assembly information. Before installation, ensure that the wall is built to outlined specifications for XHBN.WW-D-0172 in the UL directory. 9" samples are supplied with a foam tape used to represent the intumescent tape and are not fire rated.
